STUPENDO SUBWOOFER
MODELLO BASS FACE  INDY S10/2
25,00 CM 2 + 2 OHM
1000 WATT RMS E 2000 WATT MAX

CARATTERSTICHE

Specifiche principali

Tipo                                          :               Subwoofer 10"  (30cm)

Impedenza                             :                Doppia bobina da 2 ohm

Tenuta in potenza                 :                 1000 watt rms

Frequenza di risonanza        :                 35hz

Sensibilità                              :                83db

SPEAKER DATA

Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD) 1000
Overall Diameter (mm) 263
Magnet Diameter (mm) (Including Magnet Protector Where Applicable) 161
Installation Cutout Diameter (mm) 240
Overall Depth (mm) 157
Mounting Depth (mm) 260
Front Protrusion From Mounting Plane (mm) 25
Optimum Frequency Range (Hz) 20-120
Impedance (Ohm) (Nominal) 2+2
Total Magnet Weight (Oz) 124
Magnet Size 156*25
Magnet Type Y30
Magnet Qty 2
Top Plate thickness (mm) 10
Back Plate thickness (mm) 8 And Bump
Recommended Bass Enclosure Type Ported/Sealed
Recommended Bass Enclosure Volume (CuFt) 0.75-2
Recommended Bass Enclosure Tuning Frequncy (Hz) 35
Voice Coil Former Spec Aluminium
Voice Coil Type Round Wire
Voice Coil Internal Diameter (mm) 65.5
Voice Coil Winding Hight (mm) 36
Voice Coil Winding (Layers) 4
Cone Type Non Pressed Paper
Sipder Compliance Medium
Spider Type Progressive
Spider Diameter (mm) 178
Spider Design 1×1, Spacer, 1×1
Surround Tall Smooth
Surround Material Foam
Tinsel Wire Double Oversized Round Wire Stitched
Terminal 4 AWG Push

TS PARAMETERS
Revc (Ohm) 3.77
Fo (Hz) 35
Sd (Cm sq) 359.68
BL (T m) 16.106
Qms 6.844
Qes 0.692
Qts 0.628
SPL (Db) 82.4
Vas (Ltr) 17.4218
Cms (uM/N) 0.095
Krm (Ohm) 0.0027
Erm 1
Mms (g) 215.907
MMd (g) 208
Kxm (mOhm) 28.2
Exm 0.81
Xmax Both Way Total (mm) 25
Xmech Both Way Total (mm) 40
EBP 55.556
